AC Servo Motor
Anti collision
Anti Static Device
Auto Detect Material Thickness
Vacuum Pump
| Model |
UD-25C10AJV UD-25C8AJW UD-25C8AJV UD-25C8AJC |
| Maximum Print Width |
2,500mm x 1,300mm |
| Maximum Media Width |
2,500 x 1,300mm |
| Printhead |
Toshiba CE4M |
| Number of printhead |
|
|
10(C,M,Y,K,Lc,Lm,2W,2V) |
8(C,M,Y,K,Lc,Lm,2W) |
8(C,M,Y,K,2W,2V) |
8(C,M,Y,K)X2 |
| Print Speed (m2/h) |
R-Draft |
4Pass |
36 |
40 |
36 |
80 |
|
Draft |
6Pass |
22 |
24 |
22 |
48 |
|
Standard |
8Pass |
18 |
20 |
18 |
40 |
|
Quality |
12Pass |
10 |
12 |
10 |
24 |
|
High Quality |
16Pass |
8 |
10 |
8 |
20 |
| Ink |
Type |
UV Ink |
|
Color |
( C, M, Y, K, W, V ) |
| Capacity |
1L per Main Tank of Each Color |
| Ink Supply System |
Auto Ink Supply System |
| Media Type |
PS Board, KT Board, PVC Foam Board, Acrylic, Aluminum, Glass, etc |
| Cleaning System |
Auto Cleaning System |
| Print Interface |
USB 3.0 |
| Printhead Height |
1 to 100 mm from Media |
| RIP Software |
Maintop, Ultraprint, Photoprint, Onyx |
| Input Power |
AC 220V/230V, 50Hz/60Hz |
| Printer Power |
4200W |
| Vacumm Power |
1500W |
| Machine Dimension / N.W |
L3871 x W2165 x H1190mm / 825Kg |
| Package Dimension / G.W |
L4350 x W2210 x H1680mm / 1275Kg |
