Features
GEN5(7pl) Print head
Standard 4 color, up to 6 print heads
Draft qality up to 71 sqm/hr
Printing width up to 3.20m
Resolution up to 605 x 1200dpi
Technical Specification
| Print Head | 4/6 GEN5 Print Heads(7pl) | ||
| Productivity | 6Heads | ||
| Draft Mode (3pass) | 71sqm/h | ||
| Speed(4pass) | 55sqm/h | ||
| Production(6pass) | 37sqm/h | ||
| Quality(8pass) | 29sqm/h | ||
| Print resolution | Up to 605x1200dpi | ||
| Technology | Piezoelectric inkjet, Grayscale Technology ( 7 to 21 pl ) | ||
| Ink Types | LED inks | ||
| Ink Configuration | Standard CMYK | ||
| Ink cartridge size | 2.5 liter | ||
| Rip software | Photoprint Flora Edition 12 | ||
| Color management | ICC based color, adjustment curves, density adjustment | File format | Tiff, Jpeg,Postscript, EPS, PDF,etc |
| Media/Handling | Handling | Inudstry Feeding & Take-up System with Tension System | Roll media support | Support flexible media up to 330cm wide, with a roll dimension 30cm, up to 100kg in weight |
| Connectivity | |||
| Interfaces | Fast standard USB Port | ||
| Dimensions (l x w x h) | |||
| Printer | 495x120x163cm | ||
| Shipping | 502x108x165cm | ||
| Weight | |||
| 950KG | |||
| Electricity Request | |||
| Temperature | 20 to 30 °C | ||
| Relative Humidity | 35%-65%, non-condensing | ||
| Power | |||
| System | 2650W | ||
| Requirements | Input voltage: 200-240VAC, single-phase, 50/60Hz,16Amp(For System); 35Amp(For Heater) | ||
| Warranty | |||
| One year limited warranty | |||
