KM512i/30PL Print head
4/8 print heads/4 colors
Draft quality up to 243 sqm/hr
Printing width up to 3.20m
Resolution up to 720 x 1440dpi
| Print head |
4/8 KM 512i Print Heads (30pl) |
| Productivity |
|
4 Heads |
8 Heads |
|
Draft Mode (2pass) |
120sqm/h |
243sqm/h |
|
Speed (3pass) |
80sqm/h |
160sqm/h |
|
Production(4pass) |
60sqm/h |
120sqm/h |
|
Quality(8pass) |
30sqm/h |
60sqm/h |
| Print resolution |
Up to 720 x 1440dpi |
| Technology |
Piezoelectric inkjet |
| Ink types |
Solvent ink |
| Ink Configuration |
Standard CMYK |
| Ink Cartidge size |
2.5L |
| Rip Software |
Photoprint Flora Edition 10.5.1 |
| Color Management |
ICC based color, adjustment curves, density adjustment |
| File format |
Tiff, Jpeg, postscript, EPS, PDF etc |
| Media / Handling |
|
| Handling |
Industry Feedng & Take-up System with Tension System |
| Roll-feed media support |
Support flexible media up to 330cm wide, with a roll dimension 30cm, up to 100kg in weight |
| Connectivity |
|
| Interfaces |
Fast standard USP Port |
| Dimensions (l x w x h) |
|
| Printer |
485x123x147cm |
| Shipping |
502x108x165cm |
| Weight |
|
| |
850KG |
| Electricity Request |
|
| Temperature |
20 to 30 C |
| Relative Humadity |
35%-65%, non-condensing |
| Power |
|
| Heater |
3000W |
| System |
3800W |
| Requirments |
Input voltage: 210-230VAC, single-phase, 50/60Hz,16Amp(For System),
35Amp(For Heater) |
| Warranty |
|
| |
One year limited warranty |
