Variable Color Configuration + Easy Upgrade
Automatic Anti-crash Sensor
Automatic Registration Pin System
White Ink Recirculating
Automatic Media Thickness Measurement System
Dual Automatic Adjustment Negative Pressure System
| Model |
PP3220UV-G / PP2512UV-G |
EXTRA3220UV / EXTRA2512UV |
| Print Head |
2~8 Ricoh Print Heads (7-21pl) |
4~16 KM 1024i Print Heads (6-18pl) |
| Express |
45 sqm/hr |
100 sqm/hr |
| Production Mode |
35 sqm/hr |
70 sqm/hr |
| Quanlity Mode |
24 sqm/hr |
50 sqm/hr |
| Ultra Quality |
17 sqm/hr |
37 sqm/hr |
| Resolution |
Up to 605x1200 dpi |
Up to 726x1440 dpi |
| Print Technology |
Piezoelectric inkjet, Grayscale Technology |
| Ink Types |
LED inks |
| Ink Configuration |
4C/6C, W&V(Optional) |
| Ink cartridge size |
2.5 liter |
| Image process Software |
Photoprint Flora Edition 12 |
| Color management |
ICC based color, adjustment curves, density adjustment |
File format |
Tiff, Jpeg,Postscript, EPS, PDF,etc |
| Media |
|
Handling |
True vacuum table, automatic media registration pin system for easy loading
Media blow up function make it easy to unload media (Optional) |
| Print Size |
2.00 x 3.20m |
2.54 x 1.22m |
| Substrate Weight |
50kg/m² |
50kg/m² |
| Thickness |
Up to 100mm |
| Connectivity |
|
| Interfaces |
USB 3.0 |
| Curing System |
|
|
Dual shuttered UV lamps, Independent user selectable control of shutter and two
power level/LED |
| Dimensions Printer |
430 x 410 x 147cm |
480 x 260 x 144cm |
| Shipping |
430 x 230 x 165cm |
500 x 216 x 150cm |
| Weight |
2500kg(With Roll to Roll) |
2000kg(With Roll to Roll) |
| Operating Conditions |
|
| Temperature |
20℃ to 30℃ |
| Relative Humidity |
35%-65%, non-condensing(With synthetic media 40% min. recommended to avoid static electricity; with paper-based media 60% max. recommended to avoid buckling |
| Electricity Request |
|
| Power Rate |
8000Watts |
| Requirement |
Input voltage: 200 to 240VAC, single-phase, 50/60 Hz, 32A |
| Warranty |
|
|
One year limited warranty(Please contact your local dealer for accurate data) |
