| Model |
XTRA 5000 |
XTRA 3300 |
XTRA 3300L |
| Print Head |
8~16KM1024I |
5~10KM1024I |
| Draft Quanlity(2Pass) |
315sqm/h |
200sqm/h |
NA |
| Express(4Pass) |
166sqm/h |
100sqm/h |
100sqm/h |
| Production Mode(6Pass) |
80sqm/h |
73sqm/h |
73sqm/h |
| Quanlity Mode(8Pass) |
62sqm/h |
54sqm/h |
54sqm/h |
| Backlit Mode(12Pass) |
45sqm/h |
40sqm/h |
40sqm/h |
|
363*720, 363*1080, 726*720, 726*1080, 726*1440 |
| Print Technology |
Piezoelectric inkjet, Grayscale Technology |
| Ink Types |
UV/LED curable ink |
| Ink Configuration |
Standard CMYK, Lc, Lm, White(Optional) |
CMYK Plus White |
| Ink cartridge size |
5 Liter |
2.5 Liter |
| Image process Software |
Photoprint Flora Edition 10.5, Caldera, Onyx |
| Color management |
ICC based color, adjustment curves, density adjustment |
| Operating System |
Windows 7 & 8, 64bits |
| File format |
Tiff, Jpeg,Postscript, EPS, PDF,etc |
| Media |
|
Handling |
Industry feeding & Take-up System can support simultaneous printing on multiple
rolls. Daul servo motor feeding system guarantees more accurate feeding step. |
Media |
Support flexible media up to 500cm/330cm,with a roll diameter 40cm,
up to 360kg in weight ( Vinly, PET film, Blockout, Backlit, Synthetic paper, Banner, etc |
| Connectivity |
|
| Interfaces |
USB 3.0 |
| Curing System |
|
|
Dual shuttered UV lamps, Independent user selectable control of shutter and two
power level |
| Dimensions |
|
| Printer |
790*200*210cm |
610*200*210cm |
580x160x93cm |
| Weight |
|
|
5000KG(GROSS) |
3600KG(GROSS) |
2200KG(GROSS) |
| Operating Conditions |
|
| Temperature |
20 to 30°C |
| Relative Humidity |
35% - 65%, non-condensing |
| Electricity Request |
|
| Power |
4500W(System), 5000W(UV lamp) |
| Requirements |
Input voltage: 210 to 230 VAC, single-phase, 50/60Hz, 25A(System), 25A(UV lamp) |
| Air |
|
|
0.8 Bar |
| Warranty |
|
|
One year limited warranty(Please contact your local dealer for accurate data) |
Grayscale print heads, Variable Drop Size from 6pl to 18pl
